| Built-in Effects | SPX algorithm: 24 programs, PARAMETER control:1, FOOT SW:1 (FX RTN CH on/off) |
| Phantom Power | +48 V switchable, channels 1 - 12 |
| Digital I/O | USB: USB Audio Class 2.0 compliant Sampling Frequency: max 192 kHz Bit Depth: 24-bit |
| Input Channels | 8x mono [mic/line] 2x mono/stereo [mic/line] 2x stereo [line] |
| Output Channels | 2x stereo out 1x monitor out 1x headphone out 4x aux out 4x group out |
| Bus | Stereo: 1 AUX: 4 GROUP: 4 |
| Pad | 26 dB (mono) |
| HPF | 80 Hz, 12 dB/oct (mono/stereo: MIC only) |
| Compressor | Threshold: +22 dBu to -8 dBu Ratio: 1:1 to 4:1 Output level: 0 dB to 7 dB Attack time: approx. 25 msec Release time: approx. 300 msec |
| Equalizer | EQ high gain: +15 dB/-15 dB, frequency: 10 kHz shelving EQ mid gain: +15 dB/-15 dB, frequency: mono 250 Hz - 5 kHz peaking, stereo 2.5 kHz peaking EQ low gain: +15 dB/-15 dB, frequency: 100 Hz shelving |
| LED | Peak LED turns on when post EQ signal reaches 3 dB below clipping |
| Total Harmonic Distortion | 0.03% @ +14 dBu (20 Hz to 20 kHz), GAIN knob: Min, 0.005% @ +24 dBu (1 kHz), GAIN knob: Min |
| Frequency Response | +0.5 dB/-1.5 dB (20 Hz to 48 kHz), refer to the nominal output level @ 1 kHz, GAIN knob: Min |
| Equivalent Input Noise | -128 dBu (mono input channel, Rs: 150 Ω, GAIN knob: max) |
| Residual Output Noise | -102 dBu (STEREO OUT, STEREO master fader: min) |
| Crosstalk | -78 dB |
| Power Requirement | AC 100 - 240 V, 50 / 60 Hz |
| Power Consumption | 30 W |
| Dimensions | 17.5 x 5.1 x 19.7" (444 x 130 x 500 mm) |
| Net Weight | 15.0 lb (6.8 kg) |
| Packaging Info | |
|---|---|
| Package Weight | 20.0 lb |
| Box Dimensions (LxWxH) | 22.0 x 20.25 x 8.4" |
